RGBWW 5050 SMD Flexible LED Strip Programmable

The RGBWW 5050 SMD Flexible LED Strip Programmable is a controllable LED strip integrating RGB and white light, suitable for interior decoration, commercial displays, stage lighting, and architectural contour lighting.

Send Inquiry

Product Introduction

Introduction

Parameter

Item	Specification
Power	21.6 W/m
Voltage	12V / 24V DC (optional)
LEDs Quantity	60 LEDs per meter
IC Type	External IC 1906
PCB Width	10 mm
Copper Thickness	3 oz
Cutting Length	50 mm (12V) / 100 mm (24V)
Color Temp Type	SPI RGBWW
Packaging	5 m per reel
Feature	Programmable various effects
Note	Requires external controller and power supply
Packing	Anti-static bag and carton

Color	Power	CRI	Luminous (lm/m)	Cutting Length (12V)	Cutting Length (24V)
Red	4.32 W	/	140	50 mm	100 mm
Green	4.32 W	/	380	50 mm	100 mm
Blue	4.32 W	/	85	50 mm	100 mm
WW (2400K)	4.32 W	80	390	50 mm	100 mm
CW (6500K)	4.32 W	80	410	50 mm	100 mm
R+G+B+WW+CW	21.6 W	/	1405	50 mm	100 mm

product-1209-511

Features of RGBWW 5050 SMD Flexible LED Strip Programmable

High Brightness Output
The RGBWW 5050 SMD Flexible LED Strip Programmable features a 60-LED/meter structure and an RGB+WW+CW chip combination, delivering approximately 1405lm of luminous flux per meter, catering to both basic and ambient lighting needs.

Programmable Control
It incorporates an IC1906 and is controlled via SPI signals, allowing for independent segmented programming of the LEDs to achieve flowing, gradient, and dynamic lighting effects.

Stable Conductivity Structure
Utilizing a 3oz thick copper PCB reduces line resistance, maintaining stable current at 21.6W/m power and minimizing output degradation.

Flexible Mounting Structure
Based on a 10mm wide and high flexible FPC substrate, it can be bent and fitted to complex structures, suitable for installation in corners and curved spaces.

Customization

Customization Item	Description
LED Density	Adjustable number of LEDs per meter according to project requirements.
PCB Structure	Supports different PCB widths and copper thickness options.
Voltage Specification	Available in 12V or 24V configurations.
Control Protocol	Supports SPI, DMX and other control methods.
Protection Rating	Different encapsulation options from IP20 to IP65 available.
Color Temperature & Light Output	Adjustable ratio of RGB and white light for desired lighting effects.
Length & Cutting Interval	Custom reel length and cutting intervals can be set based on project needs.

FAQ

Q: How are programmable effects achieved?

A: By receiving SPI signals through the IC1906, each LED segment can be independently controlled, thus achieving various dynamic lighting effects.

Q: What are the suitable applications for the RGBWW 5050 SMD Flexible LED Strip Programmable?

A: Commonly used in scenarios requiring ambient lighting, such as commercial shop windows, interior decoration, stage backdrops, and architectural outlines.

Q: What is the power supply method?

A: It uses DC 12V or 24V power and requires a matching power adapter with the corresponding wattage.

Q: How to install and fix it?

A: It has adhesive on the back and can be directly attached to a clean, flat surface for fixation.

Q: Is a controller required?

A: An SPI controller or compatible driver is required to achieve programmable control.

Q: How to clean it?

A: Wipe the surface with a dry cloth, avoiding liquid entry into the interface area.
